39.7″, 21:9, WUHD 5120 x 2160 Auflösung, TÜV certified IPS black, 2500R curved screen, 98% DCI-P3 color gamut with factory calibration, 24-120Hz variable refresh rate, Thunderbolt™ 4 one cable solution with Thunderbolt™ out, DP out, PD3.1 140W power delivery, 2.5G RJ45, and USB ports, Daisy chain support, Lenovo® patented True Split and (e)KVM functions, Remote manageability with LDFM software; local monitor adjustment with LADM (ThinkColor) software
Beschreibung
Technische Daten
Panel
4-side Ultra Thin, In-Plane Switching
Backlight
WLED
Display Size
39.7 inches
Max View Area
- Active Area: 929.3 x 392 mm
- Screen Dimension: 942.6 x 414.5 mm
Resolution
5120 x 2160
Aspect Ratio
21:9
Pixel Pitch
0.1815 x 0.1815 mm
Dot / Pixel Per Inch
140 dpi
Brightness
400 cd/m²
Contrast Ratio
- Contrast Ratio (Typical): 2000:1
- Dynamic Contrast Ratio (Typical): 3000000:1
View Angle (H / V)
Horizontal: 178°, Vertical: 178°
Response Time
- Extreme Mode: 4ms GtG
- Normal Mode: 6ms GtG
Refresh Rate
24Hz – 120Hz
Color Gamut
- Coverage Ratio: 99% sRGB (CIE 1931)
- Coverage Ratio: 98% DCI-P3 (CIE 1976)
- Coverage Ratio: 99% BT.709 (CIE 1931)
Color Support
1.07 Billion
Color Depth
10-bit (8-bit+FRC)
Screen Surface Treatment
Anti-glare
Curvature
2500R
Operating System
Operating System
- Windows® 11 Support
- Windows® 10 Support
Multi-Media
Camera
- ThinkVision® VoIP Stack MC60 monitor webcam (For models 64B4ZAT1 and 64B4ZAR1)
- No bundled webcam (Support ThinkVision® VoIP Stack MC60 Monitor Webcam, sold separately)
Microphone
- Support MC60 with built-in dual microphone
- No built-in microphone
Speakers
- Integrated Speakers, 5W x2
- Support MS30 Monitor Soundbar, sold separately
Power Supply
Power Consumption
- Typical / Max: 41W / 300W
- Sleep / Off mode: <0.5W
- Switch-off Mode: <0.3W
- Energy Star Power On: 38.1W
- Energy Star TEC: 127kWh
- Internal Power Supply
Voltage Required
AC 100 to 240 V (50-60Hz)
Special Features
Special Features
- HDR10 Compliance
- Factory Calibration: Avg. Delta E<2 at sRGB and DCI-P3
- Picture In Picture (PIP) / Picture By Picture (PBP) Support
- Lenovo® ThinkColour (Lenovo® Accessories and Display Manager) Support
Lenovo® ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems).
Lenovo® Accessories and Display Manager is formerly Lenovo® Display Control Center. - AI Power Saving Mode
- DP Power Saving (Panel Replay)
- KVM Switch (with eKVM)
- LDFM (Lenovo® Display Fleet Manager)
- Mirrored Power Button
- Multi-sync
- Natural Low Blue Light
- Smart Power
- Smart Sensor (Ambient Light Sensor)
- True Split
Design
Mechanical
ThinkCentre M Series Support
To support Tiny devices, an additional ThinkCentre® Tiny Mounting Kit (PN:4XF1R07369) is required (sold separately).
Bezel Width
- Side: 2.0mm
- Top: 2.0mm
- Bottom: 14.1mm
Cable Management
Support
Case Color
Eclipse black
Dimensions (WxDxH)[1] Click here to see dimension diagram
| Models | Dimensions |
|---|---|
| Head Only | 947.6 x 105.3 x 419.5 mm (37.31 x 4.15 x 16.52 inches) |
| Lowest Position | 947.6 x 227.1 x 453.5 mm (37.31 x 8.94 x 17.85 inches) |
| Highest Position | 947.6 x 227.1 x 608.5 mm (37.31 x 8.94 x 23.96 inches) |
Packaging Dimensions (WxDxH)
1071.0 x 227.0 x 525.0 mm (42.17 x 8.94 x 20.67 inches)
Weight[2]
| Models | Weight |
|---|---|
| Monitor With Stand | 13.5 kg (29.8 lbs) |
| Monitor Head Only | 9.7 kg (21.4 lbs) |
Packaging Weight
20.5 kg (45.1 lbs)
Mounting
Supports VESA mount 100 x 100 mm
Stand
Supports -5° to +23.5° tilt, left & right 45° swivel, up to 155mm lift
In the Box
- Monitor with stand
- 1x DP 1.4 cable (1.8m)
- 1x USB-A to USB-B Gen 1 cable (1.8m)
- 1x Thunderbolt™ cable (1m, 40Gbps), for models 64B4Y** and 64B4X** only
- 1x Thunderbolt™ cable (1.5m, 40Gbps), for models 64B4G** and 64B4Z** only
- 1x Power cable (1.8m)
- ThinkVision® VoIP Stack MC60 monitor webcam[3]
- Factory calibration report
- Quick setup guide
Notes:
- 1. The system dimensions may vary depending on configurations.
- 2. The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
- 3. For models 64B4ZAT1**, 64B4ZAR1**, 64B4YAT1** and 64B4YAR1**
Konnektivität
Network
Ethernet
Support 2.5Gb / 1000M / 100M / 10M, 1x RJ45
Ports[1] Click here to see ports position
Rear Ports
- 1x Thunderbolt™ 4 (40Gbps) with PD 3.1 up to 140W and DisplayPort™ 1.4 Alt Mode HBR3, USB upstream
- 1x Thunderbolt™ 4 Out
- 2x USB-C® (USB 5Gbps / USB 3.2 Gen 1) with up to 15W PD, data transfer only, USB downstream
- 5x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x BC1.2, USB downstream
- 1x USB-B (USB 5Gbps / USB 3.2 Gen 1), USB upstream
- 1x HDMI® 2.1 FRL, supports 5120×2160@120Hz
- 1x DisplayPort™ 1.4 (HBR3), supports max.bandwidth 32.4Gbps
- 1x DisplayPort™ 1.4 (Out)
- 1x Ethernet (2.5GbE RJ-45)
Notes:
- 1. The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed.
USB 2.0: 480 Mbit/s;
USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s;
USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s;
USB4® 20Gbps / USB 3.2 Gen 2×2 (SuperSpeed USB 20Gbps): 20 Gbit/s;
USB4® 40Gbps (USB 40Gbps): 40 Gbit/s;
Thunderbolt™ 3/4: 40 Gbit/s.
Thunderbolt™ 5: 80 Gbit/s (bidirectional), up to 120 Gbit/s in bandwidth boost mode for video-intensive applications.
Sicherheit und Datenschutz
Security
Physical Locks
Kensington® Nano Security Slot (2.5 mm x 6 mm)
Service
Warranty
Base Warranty
3-year limited warranty
Betriebsbedingungen
Operating Environment
Temperature
Operating: 0°C to 40°C (32°F to 104°F)
Storage: -20°C to 60°C (-4°F to 140°F)
Transport: -20°C to 60°C (-4°F to 140°F)
Storage: -20°C to 60°C (-4°F to 140°F)
Transport: -20°C to 60°C (-4°F to 140°F)
Relative Humidity
Operating: 10% to 80% non-condensing
Storage: 5% to 95% non-condensing
Transport: 5% to 95% non-condensing
Storage: 5% to 95% non-condensing
Transport: 5% to 95% non-condensing
Zertifizierungen
Green Certifications[1]
Green Certifications
- ENERGY STAR® Certified
- EPEAT™ Gold Registered
- EU Energy Label (F-class)
- RoHS (2011/65/EU)
- TCO Certified, generation 10
- TCO Edge 2.1
- Volatile Organic Compound Certification
Notes:
- 1. The items listed under the „Green Certifications“ section may not only refer to certification but also registration or self-declaration. For ESG & regulatory compliance documents, please visit https://compliance.lenovo.com.
Other Certifications
Other Certifications
-
- TÜV Rheinland® IPS Black
- Eyesafe® Certified 2.0
- TÜV Rheinland® Eye Comfort Certification (5-star)
- TÜV Rheinland® Low Blue Light (Hardware Solution)
Zusätzliche Information
| Garantie | 36 Monate |
|---|
